Capacity

CW 20 G1TB

CW 37 G1TB

CW 37 G2TB

 Bottle cl. 75

18

28

28

 Variable data depending on the different packaging

 Dimensions mm

CW 20 G1TB

CW 37 G1TB

CW 37 G2TB

 External Dimensions (WxDxH)

295 x 573 x 820

380 x 578 x 820

380 x 578 x 820

 Packaging Dimensions ( WxDxH)

332 x 625 x 870

435 x 655 x 870

435 x 655 x 870

 Width

215

300

300

 Depth

445

445

445

 Height

650

650

650

 Min. Depth

325

325

325

 Min. Height

530

530

530

 Side Sticker

530 x 805

530 x 805

530 x 805

 Glass Sticker

162 x 560

247 x 560

247 x 560

Technical Features

CW 20 G1TB

CW 37 G1TB

CW 37 G2TB

 Temperature Range

+2 °C / +20 °C

+2 °C / +20 °C

+2 °C / +20 °C

+2 °C / +20 °C

 Climate Class

N-ST

N-ST

N-ST

 Net-Gross Volume

Lt. 58 / 60

Lt. 85 / 88

Lt. 80 / 85

 External Body Surface

Prepainted sheet with anticorrosion treatment

Prepainted sheet with anticorrosion treatment

Prepainted sheet with anticorrosion treatment

Porta Door

Black full glass

Black full glass

Black full glass

Inner Liner

ABS

ABS

ABS

Thermostat Thermostat

 Electronic Touch screen

 Electronic Touch screen

 Electronic Touch screen

Noise level

dB 40

dB 42

dB 40

 Insulation thickness

mm 45

mm 45

mm 45

Defrosting Defrost

Automatic compressor cycle

Automatic compressor cycle

Automatic compressor cycle

Lighting​

1 Led Vertical

1 Led Vertical

1 Led Vertical

Lock and key

Yes​

Yes​

Yes​

Reversible door

Yes​

Yes​

Yes​

Removable wooden shelves (WxD)

N° 5 – mm 447 x 199

N° 1 – mm 296 x 203

N° 5 – mm 447 x 297

N° 1 – mm 308 x 288

N° 5 – mm 447 x 297

N° 1 – mm 308 x 288

Castors -Feet

4 Feet

4 Feet

4 Feet

Net- Gross Weight

Kg 30 / 32

Kg 36 / 39

Kg 38 / 41

Voltage​

In 220

In 220

In 220

Frequency​

Hz 50

Hz 50

Hz 50

 Refrigerant

R600A

R600A

R600A

Absorption​

In 65

In 80

In 80

Energy Consumption

KwH/24H 0.35

KwH/24H 0.39

KwH/24H 0.39
